IWT ARCADIA PITLESS TUNNEL WASHER – High performance, Top quality, Highly advanced, User & Environmental friendly, Validatable, Safe cage washer! Including 5 modules as follows: 1) Loading module : 1350 mm 2) Wash module : 1500 mm 3) Pre-Rinse and Rinse module :1500 mm 4) Blowing module: 1500 mm 5) Unloading module : 900 mm • AK-KAB Validated wash at a speed of 1.2m/min • Up to 1,250 Type IIL cages per hour • Only 480 liter of water consumption per hour • Automatic conveyor and pumps pause when items are not loaded and stand-by after settable time-out for MASSIVE ENERGY SAVINGS! • 10 spraying arms with 45 wash nozzles in wash module • 4 spraying arms with 16 wash nozzles in rinse module • Vary high TTI (Total Theoretical Impact)- 0.37 • Dosing pump for one chemical agent • High dynamic pressure tool-free in-line self-cleaning filter • Interactive Polaris control and troubleshooting by 7″ touch screen interface, inclusive of: – LiteView, web based monitoring system – Teleservice, remote diagnostic package (Internet connection required) – eMeter, utilities consumption algorithmic meter for water, chemicals, electricity – Self-start feature • USB port connection for standard data gathering • Electric heating available at additional cost • Easy assembling and set-up on site. • Overall dimensions (LxWxH): 6750x1340x2122 h mm, additional width of 275mm for on board ebox All details as per data-sheet enclosed.
